SPARTUS®
ProMIG 500W DUAL PULSE
INDUSTRIAL MIG WITH DUAL PULSE
Technical parameters
| Input | ~3× 400V ± 10% 50 / 60 Hz |
| Welding current MIG [A] | 15 – 500 |
| Duty cycle | 60[%] 500[A] 100[%] 400[A] |
| MIG PARAMETERS | |
| Output working voltage MIG [V] | 14.8 – 39 |
| Wire feeding speed [m/min] | 1,5 – 24 |
| Wire diameter ∅ [mm] | 0.8 / 1.0 / 1.2 / 1.6 |
| Synergic programs |  |
| 1P - with pulse | 23 |
| 2P - with dual pulse | 23 |
| SYNERGY - without pulse | 20 |
| Pulsation/dual pulsation | |
| Dual pulse regulation | |
| dPC (pulse current delta) | 30 – 70[%] |
| FdP (Frequency 2P) | 0,5 – 3,0[Hz] |
| dut (dual pulse width) | 10 – 90[%] |
| bAL (arc length of the current) | -10 – +10 |
| Spot welding | |
| Welding inductance adjustment | Wave Control |
| Operating mode | 2T/4T/s4T |
| Operating mode s4T | |
| SCP (initial current) | 10 – 200[%] |
| SAL (initial current arc length) | -10 – +10 |
| ECP (final current) | 10 – 200[%] |
| EAL (final current arc length) | -10 – +10 |
| Slow Feed | |
| Burn Back | |
| Pre-Gas/Post-Gas | |
| SPOOL GUN | |
| TIG PARAMETERS | |
| TIG DC welding | |
| TIG welding current [A] | 10 – 500 |
| Arc ignition | Lift |
| Time of current descent [s] | 0 – 10 |
| MMA PARAMETERS | |
| Welding with MMA coated electrode | |
| MMA welding current [A] | 10 – 500 |
| Arc Force/Hot Start | |
| VRD | |
| OTHER | |
| Current consumption [A] | MIG 45/ MMA 47/ TIG 37 |
| Power factor (cosφ) | 0,70 |
| Efficiency η [%] | 85 |
| Insulation class | H |
| Protection class | IP23 |
| Weight [kg] | 102 |
| Dimensions [mm] | 1100 × 500 × 1500 |
Description:
SPARTUS® ProMIG 500W Dual Pulse is a professional, industrial welding semi-automatic with a separate wire feeder.
The factory is equipped with an integrated liquid cooler and a 4-wheeled platform, creating a solid Tower construction.
The device allows welding using MIG/MAG, TIG and MMA methods with a maximum current of 500A for all three methods. It works with a high rated 60% duty cycle and 100% duty cycle has been reached from 400A. It is powered from a 400V three-phase network.
Separated tray is equipped with a function panel with the possibility of adjusting all MIG/MAG welding parameters in manual and synergic mode. The use of a separate feeder with a full function panel increases the range of the device and has a positive effect on the quality and ergonomics of working in difficult industrial conditions. Additionally, the feeder is compatible with Spool Gun welding guns. The feeder is equipped with road wheels and a handy carrying handle.
SPARTUS® ProMIG 500W Dual Pulse has a number of functions supporting the MIG/MAG welding process, including:
•1P (Pulse) - MIG/MAG welding with pulsation, which significantly facilitates obtaining a spray arc.
•2P (Dual Pulse) - welding with dual pulse - MIG/MAG welding in TIG quality.
•welding in two work modes 2T/4T.
•spot welding.
The MIG/MAG function panel is located on a separate wire feeder, significantly increasing the range of the device and ergonomics during use. It enables adjustment of all key parameters for the MIG/MAG method, including double pulsation parameters.
Device is equipped with a function panel for precise control of welding parameters in the TIG method: welding current, 2T/4T operating mode, time of current dropping. In the MMA method, the function panel enables precise adjustment of welding current intensity, Hot Start values (easier electrode ignition), Arc Force arc dynamics (easier welding in forced positions), the ability to enable or disable the VRD function.
The SPARTUS® ProMIG 500W Dual Pulse semi-automatic welding machine is ready for use in harsh industrial environments. It has been designed and constructed for applications that require excellent quality welded joint while maintaining high welding performance.
Examples of applications: heavy industry, shipbuilding, welding of steel structures, production, high-quality and high-performance aluminum welding.
device SPARTUS® ProMIG 500W Dual Pulse:
Device SPARTUS® ProMIG 500W Dual Pulse
Separated wire feeder 4R
Cooler
Driving set
3m work clamp
User's manual
Package price [EUR]:
SPARTUS® ProMIG 500W Dual Pulse package:
Device SPARTUS® ProMIG 500W Dual Pulse
Separated wire feeder 4R
Cooler
Driving set
5m connection cable set
MIG gun SPARTUS® SPP 501LCD
3m electrode holder
3m mass cable with screw clamp
User's manual
Package price [EUR]:
NOVELTY! Choose the length of the MIG gun yourself!
The price of the package includes the option of choosing a 3-, 4- or 5-meter MIG gun.
Lack of information results in random length selection.
