SPARTUS®
EasyMIG 210LCD
SYNERGIC MIG WITH LCD DISPLAY
Technical parameters
Input | ~1× 230V ± 10% 50 / 60 Hz |
Welding current MIG [A] | 50 200 |
Duty cycle MIG [%] | 30 |
MIG PARAMETERS | |
Output working voltage MIG [V] | 12,3 26 |
Wire feeding speed [m/min] | 2 12,8 |
Wire feeder | builid-in, 2 - roll gear |
Welding wire spool [mm] | ≤ 5[kg], Ø200 |
Wire diameter Ø [mm] | Steel 0.6 / 0.8 / 1.0 Aluminium 1.0 |
2T/4T switch | ![]() |
Inductance control | ![]() |
Wire test | ![]() |
Synergy | ![]() |
Manual correction to synergy | ![]() |
MIG/MAG polarization change | ![]() |
Manual welding mode | ![]() |
TIG PARAMETERS | |
TIG welding | ![]() |
Welding current TIG [A] | 10 200 |
Duty cycle TIG [%] | 30 |
MMA PARAMETERS | |
MMA welding | ![]() |
Welding current MMA [A] | 10 160 |
Hot Start | ![]() |
Arc Force | ![]() |
VRD | ![]() |
Duty cycle MMA [%] | 60 |
OTHER | |
Max. current consumpiton [A] | MIG: 40 / MMA: 38 |
Power factor (cosφ) | 0,76 |
Insulation class | H |
Protection class | IP21S |
Weight [kg] | 12 |
Dimensions [mm] | 490 × 230 × 330 |
Network security (fuse) [A] | 25c |
Description:
SPARTUS® EasyMIG 210LCD is a modern, inverter welding semi-automatic device, based on IGBT transistors. It enables welding by means of a consumable electrode shielded by inert (MIG) or active (MAG) gases, welding with coated electrode (MMA) and TIG lift welding. In addition, the device thanks to the ability to change the polarity of welding, enables welding with flux cored welding wire without gas.
SPARTUS® EasyMIG 210LCD is equipped in synergy system for MIG/MAG welding with steel wire of 0.6 / 0.8 /1.0 mm diameter and 1.0mm aluminium wire with the ability to manually change parameters. You can choose the following programs: CO2 steel, mixed steel, aluminium, core wire welding.
The device works also in manual welding mode. Easy change of polarity allows a gas-free self-shielding wire welding.
Thanks to the use of modern technological solutions, the welder is equipped with a number of functions supporting the welding process:
- 2T / 4T - possibility to choose one of two operating modes (MIG/ MAG)
- welding inductivity regulation — face fusion width and deep control (MIG/MAG), reduction of welding splinters
- Hot Start - an easier electrode ignition (MMA)
- Arc Force - an easier welding in forced positions (MMA)
- VRD - reduced no-load voltage (MMA)
The modern LCD allows an easy and quick setting of the welding voltage and to manage the device functions. When the parameters are corrected, the display suggests the weld shape and shows graphically the recommended thickness of the material for the given current.
Examples of use: workshop, portable repair, automotive, exhaust silencer welding.
